MHI BRONTE FDCA100VNA-W
Product code:
AC3078/O
Manufacturer code
FDCA100VNAW
General Information
| Product Group : | High Wall |
|---|---|
| Condensate Water Pump Provided : | No |
| Pre-Equipped Wifi : | No |
Additional Info
| Family : | MHI Bronte |
|---|---|
| Indoor/ Outdoor/ Other : | Outdoor |
| Indoor Units Connectable (Quantity) : | 1 |
| Single Split / Multi Split : | Single Split |
Capacity
| Cooling Capacity : | 10.0 kW |
|---|---|
| Cooling Capacity (Min/Max) : | 4.0/11.2 kW |
| Cooling Capacity (Min/Rated/Max) : | 4.0/10.0/11.2 kW |
| Heating Capacity : | 11.2 kW |
| Heating Capacity (Min/Rated/Max) : | 4.0/11.2/12.5 kW |
| Heating Capacity Min/Max : | 4.0/12.5 kW |
Connections
| Pipe Diameter Gas Side : | 15.88 mm |
|---|---|
| Pipe Diameter Liquid Side : | 9.52 mm |
Cooling Capacity R32
| R32 Cooling Capacity Max : | 11.2 kW |
|---|---|
| R32 Cooling Capacity Min : | 4.0 kW |
| R32 Cooling Capacity Rated : | 10.0 kW |
Description
| Short Description : | MHI BRONTE FDCA100VNA-W Outdoor |
|---|
Electrical
| Input (Cooling) : | 3.19 kW |
|---|---|
| Input (Heating) : | 3.04 kW |
| Max Current : | 24 A |
| Power Input (Heating/Cooling) : | 3.04/3.19 kW |
| Power Supply : | 230/1/50 V/Ph/Hz |
| Voltage : | 230 V |
| Voltage 50Hz : | 230 V |
Energy Efficiency/Performance
| COP : | 3.68 |
|---|---|
| EER : | 3.13 |
| Energy Label (Cooling) : | 2.5 Average |
| Energy Label (Heating) : | 1.5 Average |
Heating Capacity R32
| R32 Heating Capacity Max : | 12.5 kW |
|---|---|
| R32 Heating Capacity Min : | 4.0 kW |
| R32 Heating Capacity Rated : | 11.2 kW |
Measurements
| Depth : | 370 mm |
|---|---|
| Height : | 845 mm |
| Net Weight : | 77 kg |
| Weight : | 77 kg |
| Width : | 970 mm |
Pipes
| Chargeless Piping Length : | 30 m |
|---|---|
| Max Height Difference : | 50 m |
| Max Height Difference (Outdoor is Higher/Lower) : | 15 m |
| Max Pipe Length Without Additional Refrigerant : | 50 m |
| Max Piping Length : | 50 m |
| Pipe Dimension : | 9.52 x 15.88 mm |
Power Input R32
| R32 Power Input Rated Cooling : | 3.19 kW |
|---|---|
| R32 Power Input Rated Heating : | 3.04 kW |
Refrigerant
| Refrigerant : | R32 |
|---|---|
| Refrigerant Amount : | 3.3 kg |
| Refrigerant Charge : | 3.3 kg |
| Refrigerant Pipe Size : | 9.52x15.88 mm |
| Refrigerant precharged up to : | 30 m |
Sound Power/Pressure
| Sound Power Level : | 69 dB(A) |
|---|
Product information
MHI BRONTE FDCA100VNA-W Outdoor
