Gree Cassette 10kW Ind R32
Product code:
AC5822/I
Manufacturer code
GUD100TBS
| Product Group : | Ceiling cassettes |
|---|
General
| Product Group : | Ceiling cassettes |
|---|
Additional Info
| Family : | Gree U Match |
|---|---|
| Indoor/ Outdoor/ Other : | Indoor |
| Single Split / Multi Split : | Single Split |
Air Volume/Air Flow
| Air Flow : | 1900 m³/h |
|---|
Cable
| Communication Cable : | 2 x 0.75 |
|---|
Connections
| Drain Connection Size : | 25 mm |
|---|---|
| Liquid Line Connection : | 9.52 mm |
| Pipe Diameter Gas Side : | 15.88 mm |
| Pipe Diameter Liquid Side : | 9.52 mm |
Connectivity
| Pre-Equipped Wifi : | Yes |
|---|
Cooling Capacity
| Cooling Capacity : | 10.1 kW |
|---|
Description
| Short Description : | Gree U Match 10Kw Cassette Indoor R32 |
|---|
Drain
| Drain Pump Height : | 1000 mm |
|---|
Electrical
| Power Consumption Cooling : | 3.04 kW |
|---|---|
| Power Consumption Heating : | 3.4 kW |
| Power Supply : | 230/1/50 V/Ph/Hz |
| Recommended Fuse : | 32 |
General Information
| Condensate Water Pump Provided : | Yes |
|---|---|
| Remote Control : | Yes |
| Remote Control Provided : | Yes |
Heating Capacity
| Heating Capacity : | 12.0 kW |
|---|
Indoor Unit Attributes
| Net Weight (IU) : | 33 kg |
|---|
Measurements
| Depth : | 840 mm |
|---|---|
| Height : | 290 mm |
| Net Weight : | 33 kg |
| Weight : | 33 kg |
| Width : | 840 mm |
Pipes
| Max Height Difference : | 30 m |
|---|---|
| Max Pipe Length Without Additional Refrigerant : | 20 m |
| Max Piping Length : | 65 m |
R32 Performances
| R32 Heating Capacity Max : | 13.5 kW |
|---|---|
| R32 Heating Capacity Min : | 3.0 kW |
| R32 Heating Capacity Rated : | 12.0 kW |
| R32 Power Input Rated Heating : | 3.4 kW |
| R32 SCOP : | 3.54 |
| R32 SEER : | 3.32 |
R32 Performances Cooling
| R32 Cooling Capacity Max : | 11 kW |
|---|---|
| R32 Cooling Capacity Min : | 3.2 kW |
| R32 Cooling Capacity Rated : | 10.1 kW |
R32 Performances Heating
| R32 Power Input Rated Cooling : | 3.04 kW |
|---|
Refrigerant
| Refrigerant : | R32 |
|---|---|
| Refrigerant Charge : | 3.02 kg |
| Refrigerant Pipe Size : | 9.52x15.88 mm |
Sound Power/Pressure
| Sound Pressure Level (Low/Medium/High/Quiet) : | 42/46/48/50 dB(A) |
|---|
Product information
Gree U Match 10Kw Cassette Indoor R32
| File name | Extension | Size |
|---|---|---|
| Technical Literature | 2.25 MB |
