Unit Freezer 4X350 Fan 4R White
Product code:
KLT113W
Manufacturer code
KLT113W
Product Group : | KLT Low Temp Evaporators |
---|
General
Product Group : | KLT Low Temp Evaporators |
---|
Connections
Liquid Line Connection : | 12.7 mm |
---|---|
Suction Line Connection : | 41.3 mm |
Description
Short Description : | The Kirby® 9000 Series Evaporator offers:• Simplified installation including factory wiring on all models for fans and heaters (excludes controls).• High airflow from the latest generation fan assemblies ensures efficient pull down and air throw.• Front o |
---|
Electrical
Electric Defrost : | Yes |
---|
Logistical Information
Gross Weight : | 62.96 kg |
---|
Measurements
Depth : | 470 mm |
---|---|
Height : | 545 mm |
Length : | 2630 mm |
Weight : | 62.96 kg |
R404A Performances
R404A Capacity @ -24SST/6KTD : | 11300 W |
---|
Product information
The Kirby® 9000 Series Evaporator has been specifically designed to overcome the usual limitations of a typical compact coil design. This low frost innovation uses a unique fin pattern to minimise latent load and maximise sensible load. Enhanced fin configuration means less moisture removal and vastly improved run times before ice formation.By increasing the ratio of fin surface to tube surface, the Kirby 9000 Series Evaporator maintains airflow as ice builds up and the coil is able to hold ice for longer. The result is more stable room conditions and longer time between defrosts as well as greater energy efficiency
File name | Extension | Size |
---|---|---|
Brochures | 1.85 MB |
