Gree R32 Inv Console 5.2kW Out
Product code:
AC7423/O
Manufacturer code
GEH18AAK6DNA1FOwi
General Information
| Product Group : | Floor Console |
|---|
Additional Info
| Family : | Gree Floor Console |
|---|---|
| Indoor/ Outdoor/ Other : | Outdoor |
| Indoor Units Connectable (Quantity) : | 1 |
| Single Split / Multi Split : | Single Split |
Capacity
| Cooling Capacity : | 5.2 kW |
|---|---|
| Cooling Capacity (Min/Rated/Max) : | 1.26/5.2/6.6 kW |
| Heating Capacity : | 5.33 kW |
| Heating Capacity (Min/Rated/Max) : | 1.12/5.33/6.8 kW |
Connections
| Liquid Line Connection : | 6.35 mm |
|---|---|
| Pipe Diameter Gas Side : | 12.50 mm |
| Pipe Diameter Liquid Side : | 6.35 mm |
Cooling Capacity R32
| R32 Cooling Capacity Max : | 6.6 kW |
|---|---|
| R32 Cooling Capacity Min : | 1.26 kW |
| R32 Cooling Capacity Rated : | 5.2 kW |
Description
| Short Description : | Gree Floor Console 5.2 Kw Outdoor R32 |
|---|
Electrical
| Input (Cooling) : | 1.575 kW |
|---|---|
| Input (Heating) : | 1.52 kW |
| Power Consumption Cooling : | 1.575 kW |
| Power Consumption Heating : | 1.52 kW |
| Power Input (Heating/Cooling) : | 1575/1.52 kW |
| Power Supply : | 230/1/50 V/Ph/Hz |
| Recommended Fuse : | 15 |
| Voltage : | 230 V |
| Voltage 50Hz : | 230 V |
Energy Efficiency/Performance
| SCOP : | 3.35 |
|---|---|
| SEER : | 3.29 |
Measurements
| Depth : | 396 mm |
|---|---|
| Height : | 700 mm |
| Weight : | 46 kg |
| Width : | 965 mm |
Pipes
| Max Height Difference : | 10 m |
|---|---|
| Max Pipe Length Without Additional Refrigerant : | 5 m |
| Max Piping Length : | 15 m |
| Pipe Dimension : | 6.35 x 12.50 mm |
Power Input R32
| R32 Power Input Rated Cooling : | 1.575 kW |
|---|
Refrigerant
| Additional Charge : | 20 g/m |
|---|---|
| Additional Gas Amount : | 20 g/m |
| Refrigerant : | R32 |
| Refrigerant Amount : | 0.95 kg |
| Refrigerant Charge : | 0.95 kg |
| Refrigerant Pipe Size : | 6.35x12.50 mm |
| Refrigerant precharged up to : | 5 m |
Sound Power/Pressure
| Sound Pressure Level : | 47 dB(A) |
|---|---|
| Sound Pressure Level Cooling : | 47 dB(A) |
| Sound Pressure Level Heating : | 57 dB(A) |
Temperature
| Temperature Range Cooling : | -15~43 °C |
|---|---|
| Temperature Range Heating : | -22~24 °C |
Product information
Gree Floor Console 5.2 Kw Outdoor R32
| File name | Extension | Size |
|---|---|---|
| Technical literature | 1.01 MB |
