CATCH-ALL C-082 DRIER

The universal acceptance of the Catch-All Filter-Drier is due to its unique moulded porous core, consisting of a blend of highly effective desiccants

The quality features built-into it assure years of service on any refrigeration system

Moisture-The Catch-All filter-drier removes moisture from the refrigerant by adsorbing and retaining it deep within the desiccant granules, the blend of desiccants used in the Catch-All Filter-Drier are specially formulated for exceptional water removal

Foreign matter-The catch-all filter-drier will filter out scale, solder particles, carbon, sludge, dirt or any other foreign matter with negligible pressure drop, fine particles that would go through an ordinary strainer are removed down to a minimum size in one pass filtration, the large filtering area of the catch-all filter-drier core permits it to collect a large amount of dirt without plug up

Oil sludge and varnish-Even the best refrigeration oils break down to produce varnish, sludge and organic acids, only the Catch-All filter-drier is capable of removing these products of oil decomposition

Moulded porous core-a unique blend of desiccants assures uniform porosity for exceptional filtration

Leaf-spring holds core firmly in place and provides shockproof assembly for rugged handling

Robust moulded core eliminates the possibility of desiccant breakdown

Corrosion-resistant coating

Copper fittings

20 um polyester pad seals core to shell wall to prevent refrigerant bypassing core, provides added filtration
