CP A 1,5 7 Y
Product code:
C5033
Manufacturer code
A 1,5 7 Y
General Information
| Product Group : | Semi Hermetic |
|---|
Compressor
| Displacement : | 6.9 m³/h |
|---|
Connections
| Discharge Line Connection : | 12.7 mm |
|---|---|
| Suction Line Connection : | 15.9 mm |
Electrical
| LRA : | 43.5 A |
|---|---|
| Voltage : | 400/3/50 V/Ph/Hz |
Measurements
| Height : | 237 mm |
|---|---|
| Weight : | 36 kg |
Nominal Capacity R134a
| R134a Nominal Capacity -5°C : | 2570 W |
|---|
Nominal Capacity R404A
| R404A Nominal Capacity -5°C : | 1680 W |
|---|
Oil
| Oil Charge : | 1000 cc |
|---|
Product information
